Step by step example

A simple mechanical example.

Import

Let us start by importing the basic input classes

from amitex.input import (
    Input,
    Grid,
    AlgorithmParameters,
    Materials,
    LoadingOutput
)

Input contains all parameters, Grid specify the grid dimensions, the last three correspond to the root nodes of AMITEX XML input files.

If not specified, all classes introduces below come from amitex.input.

Grid

Let us make a cell of 32x32x32, with voxels of side 1

grid = Grid([32, 32, 32], [1.0, 1.0, 1.0])

Algorithm

The basic algorithm parameters are defined in “node” Algorithm (importable from amitex.input), we need to set up the algorithm type and the convergence acceleration.

algorithm = Algorithm(type="Basic_Scheme", convergenceAcceleration=True)

Parameters can be set, for example to set the maximum number of iterations:

algorithm.nitermax = 3000

Most parameters can be set in the constructor, like:

algorithm = Algorithm(type="Basic_Scheme", convergenceAcceleration=True, nitermax=3000)

To set up a mechanical resolution, we nee to specify the filter and small perturbations of the Mechanics node:

mechanics = Mechanics(filter="Default", smallPerturbations=True)

Then, we gather all algorithm parameters:

algorithmParameters = AlgorithmParameters(algorithm, mechanics=mechanics)

Alternatively, one could write

algorithmParameters = AlgorithmParameters(algorithm)
algorithmParameters.mechanics = mechanics

The corresponding XML is

<Algorithm_Parameters>
        <Algorithm Type="Basic_Scheme">
                <Convergence_Criterion Value="Default"/>
                <Convergence_Acceleration Value="True"/>
        </Algorithm>
        <Mechanics>
                <Filter Type="Default"/>
                <Small_Perturbations Value="True"/>
        </Mechanics>
</Algorithm_Parameters>

Materials

Fist we need to instantiate the Materials class regrouping all material specification.

materials = Materials()

We have one isotropic elastic material

material = Material()
material.setLaw("elasiso")

We need to set the 2 coefficients for this material:

material.setCoeffs([1.0e9, 1.5e9])

To place a material, one has to define its zones, which are no more than a list of positions. Here a zone is defined on the whole cell:

zone = Zone(grid.dims())
for p in grid.allPoints():
    zone.add(p)

A zone is initialized with the dimensions of the grid (we use here grid.dims() with grid defined above). grid.allPoints() iterates over all points in the cell, each point is added.

A zone can be added to the material with

material.addZone(zone)

Note that addZone accepts more parameters to associate coefficients to a zone, for example:

material.addZone(zone, coeffs=[1.0e9, 1.5e9])

We can now add the material to the list of materials:

materials.add(material)

Finally, we need to set up the reference material:

materials.referenceMaterial = ReferenceMaterial(1.0e9, 1.5e9)

The resulting XML is

<Materials>
        <Reference_Material Lambda0="1e+09" Mu0="1.5e+09"/>
        <Material numM="1" Law="elasiso" Lib="">
                <Coeff Index="1" Type="Constant" Value="1e+09"/>
                <Coeff Index="2" Type="Constant" Value="1.5e+09"/>
        </Material>
</Materials>

Loading & Outputs

loadingOutput = LoadingOutput()

Output

Le us just switch on stress and strain VTK outputs

output = Output()
output.setVtkStressStrain(1, 1)
loadingOutput.output = output

Loading(s)

We will set up a loading ending at time 1.0 with 2 steps, with the ZZ component of the finite strain set to 0.01, and all other components will be relaxed

loading = Loading()
loading.setTimeDiscretizationLinear(2, 1.0)

The evolution of the strain component ZZ towards 0.01 can be set with:

loading.setEvolution(Component.ZZ, MechanicDriving.Strain, Evolution.Linear, 0.01)

Component contains values XX, YY, ZZ, XY… . These are tuples (I. J) where I or J are equal to 0,1,2, XX = (0, 0), XX = (0, 1) etc… MechanicDriving is an enum of values Strain and Stress, Evolution can be Linear or Constant (in the constant case, specifying a value as last parameter is not needed). This allow to set component from loops:

for i in range(3):
    for j in range(i, 3):
        if i != Component.Z or j != Component.Z:
            loading.setEvolution((i, j), MechanicDriving.Stress, Evolution.Linear, 0.0)

Here only (i,j) != ZZ and with j >= i are considered, because we are in small perturbations (for more on this the reader is referred to the official AMITEX documentation).

Then we add the loading to loadingOutput:

loadingOutput.add(loading)

Corresponding XML

The resulting XML is

<Loading_Output>
        <Output>
                <vtk_StressStrain Strain="1" Stress="1"/>
        </Output>
        <Loading Tag="1">
                <Time_Discretization Discretization="Linear" Nincr="2" Tfinal="1"/>
                <zz Driving="Strain" Evolution="Linear" Value="0.01"/>
                <xx Driving="Stress" Evolution="Linear" Value="0"/>
                <xy Driving="Stress" Evolution="Linear" Value="0"/>
                <xz Driving="Stress" Evolution="Linear" Value="0"/>
                <yy Driving="Stress" Evolution="Linear" Value="0"/>
                <yz Driving="Stress" Evolution="Linear" Value="0"/>
        </Loading>
</Loading_Output>

Input

It is now time to gather all pieces of input parameters wih the Input class

input = Input(grid, algorithmParameters, materials, loadingOutput)

This library puts all generated files to a directory (by default “amitex_dir”), it can be set with:

input.resultsDir = "my_amitex_dir"

Output files in a subdirectory output in this directory. Moreover all output filenames will have the prefix output. The total prefix can be queried with:

input.outputPrefix()

Run simulation

We can now run a simulation with AMITEX-FFTP

from amitex.simulation import runSimulationExternal
runSimulationExternal(input, numberProcs=2)

This will generate the necessary files and execute amitex_fftp. The second optional parameter sets the number of MPI processes used for amitex_fftp. By default it is set at 0, which (likely) means the number of cores on your machine will be used (mpirun is executed without -n.)

Separate generation and running steps

One could decompose the steps by first generating the input files and then generate a script from the command that would be called by runSimulationExternal.

from amitex.simulation import getSimulationShellCommand
input.generateFiles()
with open("run.sh", "w", encoding="utf-8") as file:
    file.write("#!/bin/sh\n")
    file.write(getSimulationShellCommand(input, numberProcs=2) + "\n")

Full example

from py4amitex.input import (
    Input,
    Grid,
    Algorithm,
    Mechanics,
    Material,
    Zone,
    ReferenceMaterial,
    Loading,
    Component,
    MechanicDriving,
    Evolution,
    AlgorithmParameters,
    Materials,
    LoadingOutput,
    Output
)
from py4amitex.simulation import runSimulationExternal

# 32x32x32 grid of voxels of size 1.
grid = Grid([32, 32, 32], [1.0, 1.0, 1.0])

# Set algorithm parameters
algorithm = Algorithm(type="Basic_Scheme", convergenceAcceleration=True)
# Define a mechanical resolution
mechanics = Mechanics(filter="Default", smallPerturbations=True)
algorithmParameters = AlgorithmParameters(algorithm, mechanics=mechanics)

materials = Materials()
# Define one elastic material
material = Material()
material.setLaw("elasiso")
# Lamé coefficients
material.setCoeffs([1.0e9, 1.5e9])
# Define the material on all voxels of the unit cell
zone = Zone(grid.dims())
for p in grid.allPoints():
    zone.add(p)
material.addZone(zone)
materials.add(material)
# Lamé coefficients of the reference material
materials.referenceMaterial = ReferenceMaterial(1.0e9, 1.5e9)

loadingOutput = LoadingOutput()

output = Output()
output.setVtkStressStrain(1, 1)
loadingOutput.output = output

# Define one loading
loading = Loading()
# time between 0 and 1., discretized in 2 steps;
loading.setTimeDiscretizationLinear(2, 1.0)
# Impose a strain along the zz plane, evolving to 0.01 until the final time
loading.setEvolution(Component.ZZ, MechanicDriving.Strain, Evolution.Linear, 0.01)
# Relax other directions
for i in range(3):
    for j in range(i, 3):
        if i != Component.Z or j != Component.Z:
            loading.setEvolution((i, j), MechanicDriving.Stress, Evolution.Linear, 0.0)
loadingOutput.add(loading)

# Define all input categories
input = Input(grid, algorithmParameters, materials, loadingOutput)
# Define output.std in "amitex_dir"
input.resultsDir = "amitex_dir"

# Run amitex_fftp on two processes
runSimulationExternal(input, numberProcs=2)
